J92/J92s One Design Sails
The Ultimate Sails team has been making J92 sails since the first boats arrived in the UK in the late 1990’s, we went on to help develop the IRM version in the early 2000’s and then co owned our own j92s. Through sailing the boat regularly we’ve made progressive improvements to the design of each new sail and we have been able to come up with a package that takes the boat through the full wind range without compromise. This understanding has not only allowed us to produce fast sails that suit the characteristics of the boat but also to improve the durability and help them to be fast for longer. We’ve won the J Cup with our own J92s and “Wizard of Cos” won the National Championships using the latest design Ultimate Sails.
Mainsail
Construction type: Membrane Lightwave
Surface type: UV film (Taffeta option)
Fibre type: Black Aramid
Fibre DPI: 12000
Wind range: 0 – 35 kts true
Standard Features:
- Top full length batten
- Tapered leech battens
- Laminated batten pockets
- Sail bag
- Cunningham
- Vectran leech and foot lines
- Trim stripes
- Laminated patches
- Sail numbers
- Tell tales
- Velcro clew strop
- Class logo
- Race measurement
- Class reef
Headsails
The vertical profile of the J92s Code 2 AP Jib needs to be very fair to maximize the wind speed range in which the sail operates. We’ve refined this profile to ensure that the sail generates maximum power in light winds but can then be flattened using a combination of sheet and halyard tension for strong winds. Combined with the introduction of new fibre layouts and increased fibre content, this sail is more durable and versatile than ever.
Jib Code 2 AP
Construction type: Membrane Lightwave
Surface type: UV film
Fibre type: Black Aramid
Fibre DPI: 11000
Wind range – 6 – 18 kts true
Standard Features
- Tapered leech battens
- Laminated batten pockets
- Double zip deck launch bag
- Vectran leech and foot lines
- Trim stripes
- Laminated patches
- Tell tales
- Race measurement
- Stanchion patches
Jib Code 3 ORC
Construction type: Membrane Lightwave
Surface type: UV film
Fibre type: Black Aramid
Fibre DPI: 12000
Wind range – 16 – 28 kts true
Standard Features
- tapered leech battens
- Laminated batten pockets
- Double zip deck launch bag
- Vectran leech and foot lines
- Trim stripes
- Laminated patches
- Tell tales
- Race measurement
- Stanchion patches
Asymmetric
The biggest change in sail design during the life of the class has undoubtedly been in the downwind sails and we’ve been at the forefront of these developments. Most J92s have one masthead and one fractional asymmetric so its important that the masthead sail works through a wide wind speed and wind angle range. Our latest Code 2 masthead asymmetric design is very stable and the luff rolls well to windward to allow you to sail deeper angles in light and medium conditions. This combined with stepped construction (0.9oz nylon in the high load luff area) and maximum twist in the top leech increases acceleration and helps to promote early planing for a great all round sail.
Asymmetric Code 2 MH
Construction type: Tri optimal
Material: 0.75 / 0.9oz Nylon
Apparent wind angle range: 60 – 150 deg
Apparent wind speed range: 0 – 13 kts
Standard Features
- Sail numbers
- Deck launch bag
- Vectran Luff line
- Race measurement
Asymmetric Code 3 FR
Construction type: Tri optimal
Material: 1.5oz Nylon
Apparent wind angle range: 50 – 140 deg
Apparent wind speed range: 10 – 18 kts
Standard Features
- Sail numbers
- Deck launch bag
- Vectran Luff line
- Race measurement
